Stained Glass Layout System - Squares

Stained Glass Layout System - Squares

Set the biggest panel you build; the kit composes every size up to it. Longest bars sized to fit your printer.

$6.99

FROM $14.99 printed & shipped

Snap-together bars and corners that hold the outer bounds of a stained glass panel while you build it. Tell us the biggest panel you work on and we'll create the kit. The bar ladder composes every size up to your maximum, so one box lays out hundreds of different panels.

Configure & buy

A panel is only square if something holds it square. These are the forms that do it: flat bars that snap end to end, and 90° corners that lock them into a rectangle you can build against.

The corner square is exactly the width of a bar, so it sits entirely in the crossing zone where two sides meet — which means the opening is the sum of the bar lengths and nothing else. Lay out 200 + 100 and you get a 300 mm side.

A kit for 1000 mm panels builds 780 different rectangles in 25 mm steps.

The Layout System is available in metric or imperial, whichever you're more comfortable with. The three piece clip-together case is included and sized to the kit you just created. It comes as top & bottom shells and a print-in-place hinge.

For truly interesting shapes and creative flexibility, team the up with our Ovals or Rounds kit.
